FHIR Server

FHIR Version support / Pre-requisites

As of now, ART-DECOR® support FHIR server endpoints for the following versions:

3.0 (STU 3), with the endpoint

https://serveraddress/fhir/3.0/...

4.0 (R4), with the endpoint

https://serveraddress/fhir/4.0/...

The support is provided by separate Packages that need to be installed. Please refer to the FHIR server installation instructions to learn to to set up ART-DECOR a FHIR server.

Capabilities

URI Patterns

All calls to ART-DECOR's FHIR features are to be made through FHIR version-aware endpoints.

image-20230825204317529

All URIs are using the following construct.

FHIR System URIs are everywhere. They provide business identifiers to conformance resources like StructureDefinition, ValueSet, CodeSystem and Questionnaire. They also serve to link between these resources e.g. when supplying a value set for use in a StructureDefinition.

For objects with a @canonicalUri defined, this is assumed to be correct. For objects without a @canonicalUri, it is generated from the @id of the artefact. When the id has a uri defined in the old registry, this prevails. When it is not, the generator would come up with urn:oid:[@id].

EXAMPLE

https://server/fhir/4.0/public/CodeSystem/2.16.840.1.113883.3.1937.777.71.5.9

yields URI [fhirCanonicalBase]/[type]/[id]--[effectiveDate], e.g.

https://server/fhir/4.0/CodeSystem//2.16.840.1.113883.3.1937.777.71.5.9--20200928123456

Pattern Overview

https://serveraddress/fhir/[version]/[channel]/[resource]/[id]

Base URI

https://serveraddress/fhir/

Version Identifier

FHIR Version, one of the following

FHIR VersionIdentifer to use in URI
DSTU 21.0
STU 33.0
R 44.0
R 4B4.3
R 55.0

Channel

The following channels are supported

DescriptionChannel Identifier
Trying to find the requested resource anywhere on the serverpublic
Project prefix limits scope to the requested DECOR projectproject prefix, e.g. demo1-
Project prefix + release version limits scope to the requested DECOR project releaseproject prefix + release version as digits,
e.g. demo1-20151105100336
OID Registry name limits scope to the requested OID RegistryOID Registry name, e.g. hl7org

Resource

The [resource] you would like to retrieve, e.g.

  • Bundle
  • CapabilityStatement
  • ConceptMap
  • NamingSystem
  • Questionnaire
  • QuestionnaireResponse
  • StructureDefinition
  • ValueSet
  • CodeSystem

Identifier

The id for the resource you would like to retrieve. For NamingSystem, just use the OID. For other DECOR objects, use the id--effectiveDate where you strip non-digits from the effectiveDate

Artifacts and Examples

Dataset or Transaction

Get the FHIR Logical Models for the object from any live DECOR project that has it. Any Dataset or Transaction will work, in this case the demo1- dataset.

https://art-decor.org/fhir/4.0/public/StructureDefinition/2.16.840.1.113883.3.1937.99.62.3.1.1--20120530113236

NOTE

Please note that a Dataset in DECOR has no cardinalties or conformance information. While it is illegal to omit cardinalities in FHIR Logical Models, all cardinalities are set to 0..* in case of a Dataset export. All further conformance constraints are omitted.

A transaction does have cardinalties / conformance information and this is adequately transformed into a FHIR Logical Model.

Examples

A dataset has just the structure an no cardinalities / conformance information.

image-20241012200909466

As stated above the resulting FHIR Logical Model export has no conformance information and all cardinalities are set to 0..*.

image-20241012200958544

A transaction however may have cardinalities / conformance information.

image-20241012200933992

They are translated accordingly to FHIR Logical Model constructs.

image-20241012201018121

Template

Get the Template with id xxxxx and version yyyyy from the live DECOR demo5- project.

https://art-decor.org/fhir/4.0/demo5-/StructureDefinition/xxxxx/yyyyy

Value Set

Get Value Set with id 2.16.840.1.113883.3.1937.99.62.3.11.5 and version 2011-07-25T15:22:56 from the live DECOR demo1- project.

https://art-decor.org/fhir/4.0/demo5-/ValueSet/2.16.840.1.113883.3.1937.99.62.3.11.5--20110725152256

Get Value Set with id 2.16.840.1.113883.3.1937.99.62.3.11.5 and version 2011-07-25T15:22:56 from the DECOR demo1- project release 2015-11-05T10:03:36.

https://art-decor.org/fhir/4.0/demo1-20151105100336/ValueSet/2.16.840.1.113883.3.1937.99.62.3.11.5--20110725152256

Questionnaire

Get FHIR Questionnaire derived from Transaction id 2.16.840.1.113883.3.1937.99.60.10.4.2 and version 2022-02-16T00:00:00 from the live DECOR demo10- project.

https://art-decor.org/fhir/4.0/demo10-/Questionnaire/2.16.840.1.113883.3.1937.99.60.10.4.2--20220216000000

Naming System

Get the naming system for SNOMED CT from the HL7 OID Registry.

https://art-decor.org/fhir/4.0/hl7org/NamingSystem/2.16.840.1.113883.6.96
Last Update:
Contributors: dr Kai U. Heitmann, Maarten Ligtvoet, Anne-Marie van den Boogaard
